QS Submersible Pump

QS Submersible Pump Details

QS Small Submersible Pump Operating Parameters:

Flow range: 10—250m3/h;  Head range:5—121m;   Diameter scope:φ30—φ150mm;   Temperature range: ≤30℃.

QS Small Submersible Pump Product Overview:

QS series submersible pump is widely used in various kinds of water conservancy facilities such as farm irrigation, sprinkler irrigation with water, the supply and drainage system of civil building and, industrial and draining water from the hills and mountainous area, the diversion in low-lying areas, water supply and drainage in urban and rural industrial and mining enterprises etc. The motor and water pump assembly into one, with simple structure, convenient installation remove, cover a small area, easy to use and maintain, safe and reliable operation, no water polluted, etc.

QS Small Submersible Pump Working Conditions:

The power: three-phase ac power frequency 50 Hz, voltage 380 v (allow deviation + 5%, 10%).Pumps should be safely operated, depth diving in the water not less than 0.5 meters

The water: Generally, water of no corrosion , sand content no more than 0.02%, PH 6.5 to 8.5. The temperature of the extract water is not higher than 30 ℃.

Before using, the motor lumen must be filled with the clean water, it is strictly forbidden running without water.

 QS Small Submersible Pump Characteristics:

(1). motors and pumps assembled into one,
(2). simple structure,
(3). easy installation and removal , small area,
(4). simple using and maintenance , safe and reliable operation,
(5). no pollution to water, etc.

QS Submersible Pump Application Field

Nonferrous metal ore dressing Hydraulic coal transport Hydraulic coal mining Farm drain flooded fields Artificial wetland Subway drain water station Marine boiler water supply Marine fire water supply Ballast water supply Pool and pond dredging Tunnel construction drainage Nuclear power station feed water Water pit drain water Lift lower pipe City sewage drainage and drain flooded fields Feed water、water drain Waterworks Water Tower Boiler Feed Water Building Sewage Waste Water Treatment Milk Power Production Commercial Building Heating Washing and Cleaning Pressure Pump Station Entrance Pump Station Impounding Reservoir Drinking Industry Mining Industry Water Distribution Shipping Automotive Industry Sewage Transportation Sewage Treatment Water Treatment Industrial Boiler Industrial Water Treatment Industrial Wastewater Home Building Commercial Building District Heating Pharmaceutical Industry Agricultural Pumping automobile making cooper mine Canned factory Flour mills school hospital Organic farms Fruits Garden vegetable cultivation Liquor factory Well drilling company coal mining Rig auxiliary Dressing plant Nonferrous metal tall building booster booster Asbestos cement Lime plaster Green belts garden irrigation Rubber factory/rubber plant Dye factory The tea plant Organic Ranch Beer factory soft drink factory milk factory fishing Ceramic Draw water Well drilling Oil field Fossil oil Steel mills Brick factory Pile foundation Fire-fighting Fire-fighting pressurize Pharmacy Food gem mining

QS Submersible Pump Model

Model Flow Lift Power
APKQS10-40/3 10 40 2.2
APKQS10-54/4 10 54 3
APKQS10-64/5 10 65 4
APKQS10-81/6 10 81 4
APKQS10-95/7 10 95 5.5
APKQS10-108/8 10 108 5.5
APKQS10-121/9 10 121 7.5
APKQS15-26/2 15 26 2.2
APKQS15-39/3 15 39 3
APKQS15-54/4 15 54 4
APKQS15-64/5 15 64 5.5
APKQS15-80/6 15 80 7.5
APKQS20-30/2 20 30 3
APKQS20-40/3 20 40 4
APKQS20-54/4 20 54 5.5
APKQS20-64/5 20 64 7.5
APKQS25-26/1 25 26 3
APKQS25-30/2 25 30 4
APKQS25-40/3 25 40 5.5
APKQS25-54/4 25 54 5.5
APKQS25-65/5 25 65 7.5
APKQS32-48/4 32 48 7.5
APKQS30-40/3 30 40 5.5
APKQS30-50/3 30 50 7.5
APKQS40-18/1 40 18 3
