Q Submersible Pump

Q Submersible Pump Details

Q Submersible Pump Contain:

150QJ,175QJ,200QJ,250QJ,300QJ,400QJ,QJR,QY,QD,QS etc series pump

Q Submersible Pump Product Overview :

widely used in farmland irrigation, spray irrigation and water-use, industrial and civil buildings, mountain diversion and in low-lying areas dunes, urban and rural mining supply, drainage and other water conservancy facilities.

Q using condition:
(1). 380V voltage deviation is no more than ±5%,frequency is 50HZ, three -phase power deviation is no more
than ±1%.
(2). Motor cavity must be filled with water.
(3). The first stage impeller of the pump should be more than 2mm below the moving water surface, pump unit
should be less than 70m below the static water level.
(4). The distance from the motor bottom to well bottom must be more than 3m.
(5). Water temperature should be no more than 20°C.
(6). Sand content of the water ( by mass) should be no more than 0.01%.
(7). PH value of water 6.5-8.5.
(8). Hydrogen sulfide content of the water should be no more than 1.5mg/L.
(9). Chloride ion content of the water should be no more than 400mg/L.
(10). Water yield of water source should ensure the requirements of pump continuous working.

 Material:
Impeller: Cast iron HT200,or stainless steel
Pump bowl: Cast iron HT200,or stainless steel,such as ss304, ss316, ss316L
Pump shaft : Cold-drawn steel with chrome plating,or stainless steel ss304 ss316 and ss316L
Motor Seal: Rubber O-ring seal,mechanical seal
Motor regulating sleeve: rubber

Characteristics:
1. Motors and pumps assembled into one.
2. Simple structure.
3. Easy installation and removal, small area.
4. Simple using and maintenance.
5. Safe and reliable operation, no pollution to water, etc.

Q Submersible Pump Application Field

Nonferrous metal ore dressing Hydraulic coal transport Hydraulic coal mining Farm drain flooded fields Artificial wetland Subway drain water station Marine boiler water supply Marine fire water supply Ballast water supply Pool and pond dredging Tunnel construction drainage Nuclear power station feed water Water pit drain water Lift lower pipe City sewage drainage and drain flooded fields Feed water、water drain Waterworks Water Tower Boiler Feed Water Building Sewage Waste Water Treatment Milk Power Production Commercial Building Heating Washing and Cleaning Pressure Pump Station Entrance Pump Station Impounding Reservoir Drinking Industry Mining Industry Water Distribution Shipping Automotive Industry Sewage Transportation Sewage Treatment Water Treatment Industrial Boiler Industrial Water Treatment Industrial Wastewater Home Building Commercial Building District Heating Pharmaceutical Industry Agricultural Pumping automobile making cooper mine Canned factory Flour mills school hospital Organic farms Fruits Garden vegetable cultivation Liquor factory Well drilling company coal mining Rig auxiliary Dressing plant Nonferrous metal tall building booster booster Asbestos cement Lime plaster Green belts garden irrigation Rubber factory/rubber plant Dye factory The tea plant Organic Ranch Beer factory soft drink factory milk factory fishing Ceramic Draw water Well drilling Oil field Fossil oil Steel mills Brick factory Pile foundation Fire-fighting Fire-fighting pressurize Pharmacy Food gem mining

Q Submersible Pump Model

Model Flow Lift Power
APK800Q2200-75 2200 75 710
APK800Q2200-50 2200 50 500
APK800Q2200-25 2200 25 250
APK800Q2000-93 2000 93 710
APK800Q2000-62 2000 62 500
APK800Q2000-31 2000 31 250
APK800Q1500-108 1500 93 710
APK800Q1500-72 1500 62 500
APK800Q1500-35 1500 36 250
APK600Q1100-120 1100 120 520
APK600Q1100-96 1100 96 400
APK600Q1100-72 1100 72 315
APK600Q1100-48 1100 48 225
APK600Q1100-24 1100 24 110
APK600Q900-150 900 150 520
APK600Q900-120 900 120 400
APK600Q900-90 900 90 315
APK600Q900-60 900 60 225
APK600Q900-30 900 30 110
APK600Q600-170 600 170 520
APK600Q600-136 600 136 400
APK600Q600-102 600 102 315
APK600Q600-68 600 68 225
APK600Q600-34 600 34 110
